Super Flat Cylinders
Super-Flat Cylinders are purpose-built for operations where vertical clearance is extremely limited yet heavy lifting or pressing force is required. With their pancake-style, ultra-low collapsed height and single-acting, load-return design, these cylinders make it possible to lift, align or adjust heavy loads even underneath machinery or structures where standard jacks won’t fit. Despite the compact form, they deliver substantial tonnage — up to 200 tons depending on the model — combining power with practicality for maintenance, installation, alignment and precision lifting tasks in restricted spaces.
Technical Specifications:
Cylinder Capacity : 10-100 ton.
Stroke : 10 mm.
Closed Height : 30-80 mm.
Material : Steel.
Applications:
- Positioning heavy loads during construction and infrastructure adjustments.
- Supporting and levelling components during plant shutdown and overhaul activities.
- Lifting operations under vehicles, rail equipment, and industrial machines.
- Confined-space lifting in refineries, power plants, and processing facilities.
- Jacking and separation tasks in workshops and fabrication areas.
Key Features:
Ensures simple, dependable functionality — piston extends under hydraulic pressure and returns automatically when pressure is released.
Extremely low collapsed height makes the cylinder ideal for lifting or pressing tasks in very tight, low-clearance spaces.
Specifically designed for applications where traditional hydraulic cylinders or jacks cannot be positioned — ideal for maintenance, alignment, and installation under heavy equipment or structures.
Despite the thin profile, selected models in the TSF series support heavy loads, offering flexibility to meet various lifting and pressing requirements.
Lightweight and small enough for easy placement under machinery or structural components — reducing setup complexity in confined or constrained spaces.
Manufactured with careful machining and high-quality materials to ensure consistent performance, load stability, and durability under repeated heavy use.
Product Specifications:
- Technical Data
Single Acting, Load Return
| Model No. |
Cylinder Capacity (Ton) |
Stroke (mm) |
Closed Height (mm) |
Weight (Approx) (Kg) |
| TSF-10 | 10 | 10 | 30 | 1.5 |
| TSF-20 | 20 | 10 | 35 | 2 |
| TSF-30 | 30 | 10 | 40 | 3.5 |
| TSF-50 | 50 | 10 | 50 | 7.5 |
| TSF-100 | 100 | 10 | 70 | 19 |
| TSF-150 | 150 | 10 | 75 | 31 |
| TSF-200 | 200 | 10 | 80 | 45 |
| ● Used in confined area with extermely low clearance. | ||||
| ● Ideally suited for precision lifting, alignment of machinery. | ||||
