Flat Cylinders
Flat Hydraulic Cylinders are engineered for lifting and positioning tasks where minimal clearance is available. Designed with a compact,low-profile body, these cylinders deliver high lifting force in tight, restricted spaces where standard cylinders cannot fit. Their rugged steel construction, precision-machined surfaces, and high-strength return springs ensure reliable performance under demanding industrial conditions.
Technical Specifications:
Cylinder Capacity : 5-200 ton.
Stroke : 8-16mm.
Closed Height : 35-115 mm.
Material : Steel.
Applications:
- Lifting or pressing in confined or low-clearance spaces where standard jacks or cylinders won’t fit.
- Industrial maintenance and repair — for lifting, aligning or separating heavy equipment or machinery parts.
- Equipment installation and alignment tasks where vertical clearance is limited..
- Construction and infrastructure applications requiring compact lifting/pressing tools.
- Situations requiring high-tonnage force in tight spaces — e.g. structural alignment, machinery overhaul, heavy equipment servicing.
- Any application where controlled, powerful hydraulic push is needed but working space is restricted.
Key Features:
Uses hydraulic pressure for piston extension and an internal spring for automatic retraction, ensuring fast, reliable one-direction force application after load release.
Extremely compact collapsed height allows use in very tight or restricted spaces while still delivering high lifting force across various tonnage options.
Offered in multiple capacities—providing flexibility to match different lifting, alignment, or maintenance requirements.
Engineered to deliver strong lifting performance even when vertical clearance is minimal, ideal for applications where standard cylinders cannot fit.
Built with high-strength materials and precision machining to withstand demanding industrial environments and frequent load cycles.
Protects the piston surface and improves load grip during lifting, reducing slippage and enhancing operational safety.
High-quality seals minimize leakage, extend service life, and maintain consistent performance even under heavy-duty use.
Simple hydraulic connection and spring-return mechanism ensure user-friendly setup, operation, and reduced maintenance effort.
Product Specifications:
- Technical Data
Single Acting, Spring Return
| Model No. |
Cylinder Capacity (Ton) |
Stroke (mm) |
Closed Height (mm) |
Weight (Approx) (Kg) |
| TCS-50 | 5 | 8 | 35 | 0.5 |
| TCS-100 | 10 | 12 | 45 | 1.5 |
| TCS-200 | 20 | 12 | 55 | 3 |
| TCS-300 | 30 | 12 | 60 | 4.5 |
| TCS-500 | 50 | 16 | 65 | 7 |
| TCS-750 | 75 | 16 | 80 | 13 |
| TCS-1000 | 100 | 16 | 85 | 17 |
| TCS-1500 | 150 | 16 | 100 | 30 |
| TCS-2000 | 200 | 16 | 115 | 45 |
